CAC304 / HBsC4 High Tensile Brass is a tough, corrosion resistant alloy with outstanding wear characteristics. Ideal for high load, low speed applications including Gears, Valve Stems, Bushings, Cams, Wear Rings for Pressing Dies for Wood Pulp Industry, High Strength Machine Parts.
CAC304 / HBsC4 High Tensile Brass is a tough, corrosion resistant alloy with outstanding wear characteristics. Ideal for high load, low speed applications including Gears, Valve Stems, Bushings, Cams, Wear Rings for Pressing Dies for Wood Pulp Industry, High Strength Machine Parts.
High Tensile Brass CAC302 is good in terms of strength, wear resistance, hardness and rigid. High Tensile Brass CAC302 is specialized in machining for Propellers for ships, bearings, slippers, end plates, valve seats, valve stems, special cylinders, general machine components.
High Tensile Brass CAC302 is good in terms of strength, wear resistance, hardness and rigid. High Tensile Brass CAC302 is specialized in machining for Propellers for ships, bearings, slippers, end plates, valve seats, valve stems, special cylinders, general machine components.
Busbars work as wonderful conductors and play an important role in the distribution of electricity. Busbar is a modern, space-saving and energy-saving solution for power distribution. Busbars are manufactured from pure red copper with a purity of 99.90%. Busbars not only ensure stable performance but also increase the lifespan of the electrical system because its high conductivity reached 101% IACS.
Busbars work as wonderful conductors and play an important role in the distribution of electricity. Busbar is a modern, space-saving and energy-saving solution for power distribution. Busbars are manufactured from pure red copper with a purity of 99.90%. Busbars not only ensure stable performance but also increase the lifespan of the electrical system because its high conductivity reached 101% IACS.
C10100 Pure Copper / Cu-OFE (Oxygen Free Electronic Grade) is an oxygen-free and non phosphorus-deoxidized copper with a guaranteed purity of 99.99%. C10100 Pure Copper / Cu-OFE has a minimum electrical conductivity of 101% IACS (International Annealed Copper Standard). C10100 Pure Copper / Cu-OFE is made from a high purity copper cathode CuCATH-1 (CR001A). This high purity is maintained throughout the entire manufacturing process without the addition of deoxidizing elements such as phosphorus. The consequence of this high purity is an extremely high electrical and thermal conductivity.
C10100 Pure Copper / Cu-OFE (Oxygen Free Electronic Grade) is an oxygen-free and non phosphorus-deoxidized copper with a guaranteed purity of 99.99%. C10100 Pure Copper / Cu-OFE has a minimum electrical conductivity of 101% IACS (International Annealed Copper Standard). C10100 Pure Copper / Cu-OFE is made from a high purity copper cathode CuCATH-1 (CR001A). This high purity is maintained throughout the entire manufacturing process without the addition of deoxidizing elements such as phosphorus. The consequence of this high purity is an extremely high electrical and thermal conductivity.
C83600 Leaded Gunmetal Bronze For Bushings, Sleeve Bushing, Gears, Pump & Valve Parts
Sn (Tin) | 4.55%
Zn (Zinc) | 5.85%
Pb (Lead) | 5.7%
Ni (Nickel) | 0.5%
Al (Aluminum) | 0.01%
P (phosphor) | 0.05%
Si (Silicon) | 0.02%
Cu (Copper) | Balance
* Tensile Strength | max. MPa 280
* 0.2% Proof Stress | max. MPa 115
* Elongation | max. 30%
* Hardness | 70 BHN
Standard Application | C83600, BC6, BC6C & LG2
C83600 Leaded Gunmetal Bronze For Bushings, Sleeve Bushing, Gears, Pump & Valve Parts
Sn (Tin) | 4.55%
Zn (Zinc) | 5.85%
Pb (Lead) | 5.7%
Ni (Nickel) | 0.5%
Al (Aluminum) | 0.01%
P (phosphor) | 0.05%
Si (Silicon) | 0.02%
Cu (Copper) | Balance
* Tensile Strength | max. MPa 280
* 0.2% Proof Stress | max. MPa 115
* Elongation | max. 30%
* Hardness | 70 BHN
Standard Application | C83600, BC6, BC6C & LG2
Phosphor Bronze PB1 BS1400 For Shaft Bushings, Heavy Worn Gears, Valve - Pump Parts well.
Copper Cu | 87 ~ 89.5
Tin Sn | 10 ~ 11.5
Lead Pb | max 0.25
Zinc Zn | max 0.05
Nickel Ni | max 0.10
Phosphor P | max 1.0
Aluminium Al | max 0.01
Iron Fe | max 0.1
Antimony | max 0.05
Sulphur | max 0.05
Silicon | max 0.01
Bismuth | max 0.05
Tensile strength (N/mm2) | 350
Proof strength (N/mm2) | 170
Elongation % | 4 ~ 6
Density (g/cmᶟ) | Approx. 8.7
Hardness | 110 BHN
Phosphor Bronze PB1 BS1400 For Shaft Bushings, Heavy Worn Gears, Valve - Pump Parts well.
Copper Cu | 87 ~ 89.5
Tin Sn | 10 ~ 11.5
Lead Pb | max 0.25
Zinc Zn | max 0.05
Nickel Ni | max 0.10
Phosphor P | max 1.0
Aluminium Al | max 0.01
Iron Fe | max 0.1
Antimony | max 0.05
Sulphur | max 0.05
Silicon | max 0.01
Bismuth | max 0.05
Tensile strength (N/mm2) | 350
Proof strength (N/mm2) | 170
Elongation % | 4 ~ 6
Density (g/cmᶟ) | Approx. 8.7
Hardness | 110 BHN
CAC603 Leaded Tin Bronze is good in terms of pressure resistance and wear resistance, and thus is suitable for bearings. It is good in terms of affinity and thus is used for middle-speed and heavy-load bearings, bearings for big-size engines, back panels of white metals, bushings for high-speed, railroad cars, etc.
Mechanical Properties - CAC603 Leaded Tin Bronze:
%Cu | 77.0~81.0
%Sn | 9.0~11.0
%Pb | 9.0~11.0
%Zn | 0.0~0.10
%Fe | 0.0~0.30
%Ni | 0.0~0.10
%P | 0.0~0.10
Tensile strength | 35 PSI
Yield strength | 20 PSI
Elongation | 6%
Hardness Brinell 500kg | min 60 BHN
CAC603 Leaded Tin Bronze is good in terms of pressure resistance and wear resistance, and thus is suitable for bearings. It is good in terms of affinity and thus is used for middle-speed and heavy-load bearings, bearings for big-size engines, back panels of white metals, bushings for high-speed, railroad cars, etc.
Mechanical Properties - CAC603 Leaded Tin Bronze:
%Cu | 77.0~81.0
%Sn | 9.0~11.0
%Pb | 9.0~11.0
%Zn | 0.0~0.10
%Fe | 0.0~0.30
%Ni | 0.0~0.10
%P | 0.0~0.10
Tensile strength | 35 PSI
Yield strength | 20 PSI
Elongation | 6%
Hardness Brinell 500kg | min 60 BHN
C90300 SAE620 Bearing Bronze
Copper (Cu) | 86.0 ~ 89.0%
Tin (Sn) | 7.50 ~ 9.0%
Lead (Pb) | max. 0.30%
Zicum (Zn) | 3.0 ~ 5.0%
Furrum (Fe) | max. 0.20%
Nickel (Ni) | max. 1.0%
Stibium (Sb) | max. 0.2%
Phosphor (P) | max. 1.50
Sulfur (S) | max. 0.05%
Alluminium (Al) | max. 0.005%
Silic (Si) | max. 0.005%
Tensile Strength(Mpa, min.) | 303 0.5%
Yield Strength(MPa, min.) | 152
Elongation(min. %) | 18
C90300 SAE620 Bearing Bronze
Copper (Cu) | 86.0 ~ 89.0%
Tin (Sn) | 7.50 ~ 9.0%
Lead (Pb) | max. 0.30%
Zicum (Zn) | 3.0 ~ 5.0%
Furrum (Fe) | max. 0.20%
Nickel (Ni) | max. 1.0%
Stibium (Sb) | max. 0.2%
Phosphor (P) | max. 1.50
Sulfur (S) | max. 0.05%
Alluminium (Al) | max. 0.005%
Silic (Si) | max. 0.005%
Tensile Strength(Mpa, min.) | 303 0.5%
Yield Strength(MPa, min.) | 152
Elongation(min. %) | 18
C6191 Aluminum Bronze has excellent wear resistance - corrosion resistance - fatigue resistance for good for Nut, Worm gears, Bush, Mold, Spiral gears.
Copper (%Cu, min) | 81.0~88.0
Alluminium (%Al) | 8.0~11.0
Furrum (%Fe) | 3.0~5.0
Nickel (%Ni) | 0.5 ~ 2.0
Manganum (%Mn) | 0.5 ~ 2.0
Tensile Strength (Mpa, min.) | 500 ~ 900
Elongation(min. %) | 40 ~ 5
Hardness (HBW, min) | 110 ~ 200
C6191 Aluminum Bronze has excellent wear resistance - corrosion resistance - fatigue resistance for good for Nut, Worm gears, Bush, Mold, Spiral gears.
Copper (%Cu, min) | 81.0~88.0
Alluminium (%Al) | 8.0~11.0
Furrum (%Fe) | 3.0~5.0
Nickel (%Ni) | 0.5 ~ 2.0
Manganum (%Mn) | 0.5 ~ 2.0
Tensile Strength (Mpa, min.) | 500 ~ 900
Elongation(min. %) | 40 ~ 5
Hardness (HBW, min) | 110 ~ 200
Copper (Cu) | 81.0 ~ 85.0%
Tin (Sn) | 6.3 ~ 7.5%
Lead (Pb) |6.0 ~ 8.0%
Zicum (Zn) | 2.0 ~ 4.0%
Furrum (Fe) | max 0.20%
Nickel (Ni) | max 1.0%
Stibium (Sb) | max 0.35%
Phosphor (P) | max 1.50
Sulfur (S) | max 0.08%
Alluminium (Al) | max 0.005%
Silic (Si) | max 0.005%
Tensile Strength (Mpa, min.) | 241
0.5% Yield Strength(MPa, min.) | 138
Elongation(min. %) | 10
Copper (Cu) | 81.0 ~ 85.0%
Tin (Sn) | 6.3 ~ 7.5%
Lead (Pb) |6.0 ~ 8.0%
Zicum (Zn) | 2.0 ~ 4.0%
Furrum (Fe) | max 0.20%
Nickel (Ni) | max 1.0%
Stibium (Sb) | max 0.35%
Phosphor (P) | max 1.50
Sulfur (S) | max 0.08%
Alluminium (Al) | max 0.005%
Silic (Si) | max 0.005%
Tensile Strength (Mpa, min.) | 241
0.5% Yield Strength(MPa, min.) | 138
Elongation(min. %) | 10
Đồng nguyên chất (Cu) | 98.0 ~ 99.0%
Chromium (Cr) | 0.5 ~ 1.5%
Ziconium (Zr) | 0.05 ~ 0.25%
Electrical Conductivity (%IACS) | 80.0 ~ 85.0%
Sức căng ( Tensile strength) | 50 ~ 70 KSI
Hệ số giãn nở nhiệt ×106/K(20～300℃) | 16.45
Tỉ trọng | 8.89
Giới hạn nóng chảy | 1080 C
Giới hạn kết tinh | 1070 C
Modul đàn hỗi (kN/mm2) | 117000
Độ dẫn nhiệt | 187.0 Btu
Độ cứng | 72 ~ 85 HRB
Đồng nguyên chất (Cu) | 98.0 ~ 99.0%
Chromium (Cr) | 0.5 ~ 1.5%
Ziconium (Zr) | 0.05 ~ 0.25%
Electrical Conductivity (%IACS) | 80.0 ~ 85.0%
Sức căng ( Tensile strength) | 50 ~ 70 KSI
Hệ số giãn nở nhiệt ×106/K(20～300℃) | 16.45
Tỉ trọng | 8.89
Giới hạn nóng chảy | 1080 C
Giới hạn kết tinh | 1070 C
Modul đàn hỗi (kN/mm2) | 117000
Độ dẫn nhiệt | 187.0 Btu
Độ cứng | 72 ~ 85 HRB
Copper (Cu) | 88 ~ 90%
Sn | 10~12%
Lead (Pb) | 0.50%
Furrum (Fe) | 0.15%
Nickel (Ni) | 0.5%
Stibium (Sb) | 0.2%
Phosphor (P) | 0.3%
Sulfur (S) | 0.05%
Alluminium (Al) | 0.005%
Mn | max. 0.2%
Silic (Si) | 0.005%
Zn | max. 0.5%
Tensile Strength(Mpa, min.) | 276
0.5% Yield Strength(MPa, min.) | 172
Elongation(min. %) | 10
Hardness (min.HRB) | 102
Copper (Cu) | 88 ~ 90%
Sn | 10~12%
Lead (Pb) | 0.50%
Furrum (Fe) | 0.15%
Nickel (Ni) | 0.5%
Stibium (Sb) | 0.2%
Phosphor (P) | 0.3%
Sulfur (S) | 0.05%
Alluminium (Al) | 0.005%
Mn | max. 0.2%
Silic (Si) | 0.005%
Zn | max. 0.5%
Tensile Strength(Mpa, min.) | 276
0.5% Yield Strength(MPa, min.) | 172
Elongation(min. %) | 10
Hardness (min.HRB) | 102
